Main Application Scenarios:
Industrial parks, factories, schools and universities, government facilities, railway and bus stations, airports, hospitals, and other commercial or public facilities.
Installation Projects
Available from 6 meters upward — including 6m, 8m, 10m, 12m, 15m, 20m, and fully customized dimensions upon request. Based on your site conditions, traffic patterns, and project requirements, we provide fully engineered access solutions tailored to your specific needs. Whether it involves telescopic sliding gates, cantilever gates, barrier systems, or integrated automation, each project is designed as a comprehensive solution to ensure optimal structural strength, space efficiency, operational reliability, and long-term performance.
In industrial parks, factories, logistics centers, commercial complexes, schools, ports, and other high-traffic facilities, entrances often have limited retraction space while handling frequent vehicle and pedestrian flow. These environments demand gates that can operate quickly, safely, and continuously, even in peak traffic periods.
Traditional single-panel sliding gates require long back-run distances and are often restricted by walls, landscaping, or parked vehicles. They can experience structural stress over large openings and frequent use, leading to increased maintenance. Telescopic sliding gates overcome these limitations with a multi-panel, synchronized design that maximizes opening width while minimizing sliding distance.
- Multi-panel telescopic structure — allows the gate to retract in a compact footprint, making it ideal for entrances with limited space while maintaining full-width clearance.
- Heavy-duty reinforced steel frame and precision linkage — ensures smooth, synchronized movement and stability across wide spans, supporting frequent daily operation.
- Engineered for high-frequency use — perfect for industrial parks, logistics hubs, schools, and transportation facilities where gates must operate reliably with minimal downtime.
- Integration-ready with automation systems — fully compatible with electric motors, access control, safety sensors, and other intelligent management solutions for enhanced operational efficiency.
- Low-maintenance, durable design — built to deliver years of dependable operation with minimal upkeep, reducing operational costs across the gate’s lifecycle.
- A telescopic sliding gate customized as part of a comprehensive site solution delivers efficient, safe, and reliable access control tailored to the specific demands of your industrial, commercial, or institutional project.
Product Specifications
- The limit length of the automatic cantilever sliding gate body is 18 meters (see light 12 meters), the automatic sliding gate body running speed: 12 meters per minute, motor power: 450W.
- The front section of the automatic cantilever sliding gate is equipped with anti-collision rubber strips, and an infrared anti-collision device is installed between the two gantry frames, which can better protect the safety of people and the sliding gate body.
- The automatic sliding cantilever gate body is completely suspended in the air and is not restricted by any ground. It is suitable for operation in various environments such as high temperature, high cold, wind, rain, ice, snow, slopes, above grass, above railways, etc.
- The cantilever sliding gate motor is equipped with an overheating and overload protection device. When the motor reaches a certain temperature in continuous operation, it will automatically cut off the power and enter the protection state to prolong the service life of the motor.
- The external motor is driven through the gear and the rack, closely matched without slipping, fast heat dissipation and protected by a separate chassis, the appearance is atmospheric and safe, and the maintenance, inspection and repair of the motor are convenient and fast.
- The automatic cantilever sliding gate body is made of high-quality 6063 aluminum alloy, without welding points, the overall shape is beautiful and generous, durable, and not easy to rust.
- There is a set of infrared anti-climbing devices installed on the top of the cantilever sliding gate. When the automatic cantilever sliding gate is closed and someone climbs over the sliding gate, the alarm horn will sound an alarm.
- Anti-collision function: In the state of closing the sliding gate, the intelligent infrared anti-collision can stop immediately and return automatically when encountering people or objects.
telescopic sliding gate tructure and function
High-power motor
Automatic telescopic gate motor is equipped with overheating and overload protection devices .The motor runs continuously up to a .When the temperature is set, it will automatically cut off the power and enter the protection state to prolong the service life of the motor.
High-density aluminum
Telescopic gate main beam is made of high-strength carbon steel or aluminum alloy, and the structure is firm.Hot dip galvanizing + spraying treatment, rich colors, more choices.
Intelligent infrared sen device
Optional anti-pinch, anti-collision function, in the opening/closing operation state, the mechanical anti-pinch switch device is touched, the rubber strip by people or objects will trigger the anti-pinch anti-collision function, touch the door can be quickly cut off to stop operation, to ensure safety.
Running smoothly
The gate body is designed to operate in sections. Each section of the gate body has an independent chassis and axle wheel, which is stable in operation and elegant in appearance.
